Bianco AE PLC Fully Automatic Single Mitre Bandsaw
The Bianco AE Fully Automatic Single Mitre Bandsaws 415v are esteemed for their reliability, dependability and high accuracy which are hallmarks of Bianco Bandsaws.
Bianco have been manufacturing bandsaws in Italy for over thirty years and have built a reputation for producing precise, reliable, and accurate machines. All machines have modern cast bows from special alloys to ensure one of the highest precision bandsaw ranges available.
Optional - Blade Deflection Device
Optional - Variable Blade Speed
Optional - Digital Read-Out Angle Finder
Optional - Dry Cooling Device
Optional - Hydraulic Bundle Clamping
Optional - Inverter
Optional - Variable Vice Pressure
Optional - Mechanical Bundle Clamping
| MODEL | 330AE PLC | 370AE PLC | 420AE PLC | |||||||||
| STOCKCODE | 15063 | 15100 | 15508 | |||||||||
| Capacity | 90° | 45° | 60° | 90° | 45° | 60° | 90° | 45° | 60° | |||
| ◯ Tube | mm | 260 | 200 | 120 | 280 | 225 | 140 | 300 | 240 | 165 | ||
| □ Box Section | mm | 240 | 190 | 115 | 240 | 215 | 140 | 240 | 230 | 170 | ||
| ▭ Widest Cut | mm | 330 x 120 | 200 x 130 | 120 x 100 | 330 x 240 | 230 x 140 | 140 x 130 | 420 x 200 | 270 x 140 | 170 x 170 | ||
| Bed Height | mm | 835 | 835 | 835 | ||||||||
| Blade Size | mm | 3010 x 27 x 0.9 | 3120 x 27 x 0.9 | 3270 x 27 x 0.9 | ||||||||
| Cutting Speed | m/min | 35/70 | 10 – 100 | 10 – 100 | ||||||||
| Motor | Kw | 0.9 – 1.4 | 0.9 – 1.4 | 0.9 – 1.4 | ||||||||
| Length | mm | 2330 | 2800 | 2800 | ||||||||
| Width | mm | 1520 | 1950 | 2050 | ||||||||
| Height | mm | 1800 | 1850 | 1900 | ||||||||
| Weight | Kg | 655 | 945 | 1090 | ||||||||
| Operation | Automatic | Automatic | Automatic | |||||||||
| Vice | Hydraulic | Hydraulic | Hydraulic | |||||||||
| Remnant Piece | mm | 220 | 220 | 220 | ||||||||
| Carriage Stroke | mm | 600 | 600 | 600 |
*When cutting solid bar, a maximum of 150mm is recommended in Auto mode, beyond should be cut in manual mode.
Features
- Hydraulic cutting with variable pressure and variable speed
- Hydraulic vice
- Fast approach with auto bow height return setting
- Cast bow construction
- Carbide blade guides for high accuracy
- Quick mitring swivel head up to 60°
- Fully automatic cutting cycle with hydraulic vice feed system
- Shuttle vice facility for long cutting lengths
- Scrap length 225mm
Options
- Blade speed variation
- Spray mist cooling system
- Chip conveyor
- Hydraulic bundle cutting
- Variable clamping pressure
- Roller track and measuring systems
