Morgan Rushworth PBH Hydraulic H Frame Pressbrake 415V

Main view Morgan-Rushworth-PBH-H-Frame

The heavily constructed PBH press brake model is of an H frame design and is fitted with heavy duty top and bottom press brake tools, ideal for a whole variety of heavier bending operations. These models feature adjustable limit switches for ram stroke and return, as well as twin guidance pistons in addition to the main ram. The machine operates at a safe working speed and is also fitted with a two handed control to ensure the operator is well away from the working area. These are a great alternative to a full form press brake.

Main view Morgan-Rushworth-PBH-H-Frame
Main view Morgan-Rushworth-PBH-H-FrameMain view Morgan-Rushworth-PBH-H-Frame
Video thumbnail showing the Morgan Rushworth PBH Hydraulic H Frame Pressbrake 415V
MODELSTOCK CODEA mmC mmmm/secmm secmm seckwL mmH mmW mmkg
PBH 1020/100M5260100102030085107.52050100022201900
PBH 1520/100M5261100152030085107.52500100022202500
PBH 1020/150M526215010203009510112050100023802400
PBH 1520/150M526315015203009510112500100023803100


  • Very heavy H frame design
  • Top & bottom press brake tooling
  • Safe working speed
  • Quiet hydraulic system
  • Stepless pressure adjustment
  • Hydraulic cylinder mounted above tooling providing vertical pressure
  • Twin guidance pistons in addition to the main ram
  • Stepless stroke adjustment with limit switches controlling the ram stroke and return
  • Adjustable bed height with two hardened pins
  • Control console with two handed operation
  • Ideal for low or high volume operation
