MODEL | 370A CNC | 420A CNC | 370AF CNC | |||||||
STOCKCODE | 15076 | 15110 | 15112 | |||||||
Capacity | 90° | 45° | 60° | 90° | 45° | 60° | 90° | |||
Round | mm | 280 | 225 | 140 | 300 | 240 | 165 | 380 | ||
Square | mm | 240 | 215 | 140 | 240 | 230 | 170 | 240 | ||
Rectangle | mm | 330 x 240 | 230 x 140 | 140 x 130 | 420 x 180 | 250 x 180 | 170 x 170 | 330 x 240 | ||
Bed Height | mm | 835 | 835 | 835 | ||||||
Blade Size | mm | 3120 x 27 x 0.9 | 3270 x 27 x 0.9 | 3120 x 27 x 0.9 | ||||||
Cutting Speed | m/min | 10 – 100 | 35 – 70 | 35 – 70 | ||||||
Motor | Kw | 1.5 | 1.5 | 1.5 | ||||||
Length | mm | 2800 | 3220 | 2850 | ||||||
Width | mm | 1950 | 1950 | 1900 | ||||||
Height | mm | 1850 | 1900 | 1900 | ||||||
Weight | Kg | 945 | 1000 | 945 | ||||||
Operation | CNC Automatic | CNC Automatic | CNC Automatic | |||||||
Vice | Hydraulic | Hydraulic | Hydraulic |
Features
- CNC control programmer for varying cutting lengths, quantities and right angled
- Fully automatic cutting cycle with hydraulic vice feed system.
- Shuttle vice facility for long cutting lengths.
- Hydraulic cutting with variable pressure and variable speed.
- Hydraulic vice.
- Fast approach with auto bow height return setting.
- Cast bow construction.
- Carbide blade guides for high accuracy.
- Chip conveyor.
- Powered swarf brush.
- Blade speed variator.
Options
- Spray mist cooling system.
- Hydraulic bundle cutting.
- Variable clamping pressure.
