Promotech PPCM 650 CNC Pipe &Tube Profile Plasma Cutting Machine


The Promotech PPCM 650 CNC Pipe &Tube Profile Plasma Cutting Machine offers extremely accurate and efficient cutting and bevelling of pipe and tube. Capacities start from 50mm and increase to a maximum of 650mm outside diameter with the ability to handle lengths up to 12m. The PPCM 650 also gives the option of cutting with oxyfuel or plasma. User friendly software allows for quick and efficient use of PPCM machines after basic training. CNC data file transfer to PPCM from CAD/CAM software available as option.

Technical Spec

Minimum Pipe Diametermm50
Maximum Pipe Diametermm650
Minimum Wall Thickness at 45ºmm3
Maximum Wall Thickness at 45ºmm45
Maximum Pipe Lengthmm6000
Minimum Pipe Lengthmm380
Spindle Bore Diametermm130


  • Fume extraction system
  • 9M or 12M long pipe length capacity
  • Additional pipe supports


  • Oxy-fuel or plasma cutting capability
  • Large capacity pipe notching up to 650mm
  • Able to cut or bevel holes along the length of the pipe
  • Able to bevel and notch pipe simultaneously
  • Laser pointer
  • Two pipe supports – two tonne capacity each
  • User friendly CNC controller with only basic training required
